Embedded World Expo

ATI will be exhibiting at Embedded World Expo on March 14th to the 16th. Meet the team at booth 4-156 in hall 4 and experience ATI's comprehensive portfolio of MCD solutions. Live demonstrations will be available for a variety of products including ATI's Vehicle Communication Gateway. As industry brings in new technology with new physical and transport layers, engineers are struggling to find a way to begin development with little to no hardware. ATI’s Vehicle Communication Gateway, allows users to take existing hardware and convert the physical and transport layers into the new bus.

Products Featured at Show

Vehicle Communication Gateway

The VCG-1 Vehicle Communication Gateway is an easy to configure, multi-port, multi-bus message routing and data translation device. Designed to normally operate standalone, it can help bridge multiple modules as systems transition to newer communication busses and technologies, such as CAN-FD and Automotive Ethernet

Automotive Ethernet Adaptor

The ATI Automotive Ethernet Adapters are bi-directional physical layer media converters which converts between standard 100Base-T Ethernet and 100Base-T1 Automotive Ethernet. The AE-1000 has the added feature of supporting conversions between 1000Base-T Ethernet and 1000Base-T1 (OPEN Alliance BroadR-Reach (OABR) compatible) Automotive Ethernet via a user-selectable switch .

VISION Calibration and Data Acquisition Software

VISION Calibration and Data Acquisition Software is a powerful collection of toolkits that can be seamlessly grouped together in combinations to provide an integrated customizable application that is capable of the entire range of calibration and data acquisition functions including data collection from electronic control units and external sources, measurement of relationships between inputs and outputs, real-time calibration and modification of closed loop control systems, time alignment and analysis of all information, management of calibration data changes, and programming of electronic control units (ECUs).

CANary Interfaces

CANary and CANary FD are a pocket sized CAN interface for ATI's VISION calibration and Data Acquisition system. Both use CAN channels to bridge data between ATI’s data acquisition hardware, ECUs (using CCP or XCP), or other CAN devices that are compatible with VISION Calibration and Data Acquisition Software. These devices include ATI’s EMX Data Acquisition Series and most third party data acquisition modules.

A9 Serial ECU Interface

The A9 ECU Interface product is a high-speed ECU interface that efficiently communicates to an ECU over the processor’s DAP interface. To use the A9, a simple plug-and-play gigabit Ethernet interface can be connected directly to a PC or standard LAN, eliminating any need for expensive interface boxes. Hardware IEEE-1588 PTP time synchronization ensures accurate correlation to other acquired data.

DLX Datalogger

The DLX Datalogger offers a unique combination of functions that provide the features of a CAN interface, data acquisition module, and data logger all in one compact package. Communication channels include CAN and K-line that interface to ECUs or communicate with ATI data acquisition hardware.
